한양대 / 신방호, 김찬형*
Abstract
Objective.The red bone marrow (RBM) and bone endosteum (BE), which are required for effective dose calculation, are macroscopically modeled in the reference phantoms of the international commission on radiological protection (ICRP) due to their microscopic and complex histology. In the present study, the detailed bone models were developed to simplify the dose calculation process for skeletal dosimetry.Approach.The detailed bone models were developed based on the bone models developed at the University of Florida. A new method was used to update the definition of BE region by storing the BE location indices using virtual sub-voxels. The detailed bone models were then installed in the spongiosa regions of the ICRP mesh-type reference computational phantoms (MRCPs) via the parallel geometry feature of the Geant4 code.Main results.Comparing the results between the detailed-bone-installed MRCPs and the original MRCPs with the absorbed dose to spongiosa and fluence-to-dose response function (DRF)-based methods, the DRF-based method showed much smaller but still significant differences. Compared with the values given in ICRPPublications116 and 133, the differences were very large (i.e. several orders of magnitudes), due mainly to the anatomical improvement of the skeletal system in the MRCPs; that is, spongiosa and medullary cavity are fully enclosed by cortical bone in the MRCPs but not in the ICRP-110 phantoms.Significance.The detailed bone models enable the direct calculation of the absorbed doses to the RBM and BE, simplifying the dose calculation process and potentially improving the consistency and accuracy of skeletal dosimetry.
Geant4 코드의 parallel world 기능을 이용하여 복셀 기반의 상세 뼈 모델을 ICRP 메시형 표준 인체전산팬텀의 경추에 설치한 모습
Affiliations
Bangho Shin 1, Yeon Soo Yeom 2, Chansoo Choi 1 3, Wesley E Bolch 3, Haegin Han 1, Thang Tat Nguyen 4, Sungho Moon 1, Gahee Son 1, Suhyeon Kim 1, Hyeonil Kim 1, Chan Hyeong Kim 1
1Department of Nuclear Engineering, Hanyang University, Seoul, Republic of Korea.
2Department of Radiation Convergence Engineering, Yonsei University, Wonju, Republic of Korea.
3J Crayton Pruitt Family Department of Biomedical Engineering, University of Florida, Gainesville, FL, United States of America.
4Department of Nuclear Engineering and Environmental Physics, Hanoi University of Science and Technology, Hanoi, Vietnam.
